2 Port Plant Valve - 2 Port 20mm Stroke PN16 Ext Thread 15mm Kvs 0.6
SKU V5011E1165
Original price
£218.98
-
Original price
£218.98
Original price
£218.98
£218.98
-
£218.98
Current price
£218.98
Plant Valve - 2 Port 20mm Stroke PN16 Ext Thread 15mm Kvs 0.6 - Datasheet en0b0064
 |
|
| Valve type | 2-way |
| Materials | body brass, stem stainless steel; plug brass |
| Action to open | stem up |
| Stroke | 20 mm |
| Media temp. | 2 ... 170 oC |
| Pressure rating | PN16 |
| Port connection | ext. thread flat sealing |
| Flow char. | mod.equal% |
| Medium type | water |
|
||||||||||||||||||||
| DN size | Connection diameter | Kvs value | Close off pressure with 600N motor | Close off pressure with 1800N motor | Type | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | kPa | kPa | |||||||||||||||||
| 15 | G1 1/8 | 0,63 | 1600 | — |
Specification sheet (English) |
|||||||||||||||
| 15 | G1 1/8 | 1 | 1600 | — |
Specification sheet (English) |
|||||||||||||||
| 15 | G1 1/8 | 1,6 | 1600 | — |
Specification sheet (English) |
|||||||||||||||
| 15 | G1 1/8 | 2,5 | 1600 | — |
Specification sheet (English) |
|||||||||||||||
| 15 | G1 1/8 | 4 | 1600 | — |
Specification sheet (English) |
|||||||||||||||
| 20 | G1 1/4 | 6,3 | 1600 | — |
Specification sheet (English) |
|||||||||||||||
| 25 | G1 1/2 | 10 | 1000 | 1600 |
Specification sheet (English) |
|||||||||||||||
| 32 | G2 | 16 | 700 | 1600 |
Specification sheet (English) |
|||||||||||||||
| 40 | G2 1/4 | 25 | 460 | 1500 |
Specification sheet (English) |
|||||||||||||||
| 50 | G2 3/4 | 40 | 260 | 850 |
Specification sheet (English) |
|||||||||||||||
