2 Port Plant Valve - 2 Port 20mm Stroke PN16 Ext Thread 15mm Kvs 2.5

by Energy Controls Online
SKU V5011E1197
£183.50 - £183.50
£183.50
£183.50 - £183.50
£183.50

Plant Valve - 2 Port 20mm Stroke PN16 Ext Thread 15mm Kvs 2.5 - Datasheet en0b0085



v5011e-ge51
For heating, ventilating and air conditioning, domestic hot water, open circuits; hot/cold water quality VDI2035.
Valve type 2-way
Materials body brass, stem stainless steel; plug brass
Action to open stem up
Stroke 20 mm
Media temp. 2 ... 170 oC
Pressure rating PN16
Port connection ext. thread flat sealing
Flow char. mod.equal%
Medium type water
20 mm
DN size Connection diameter Kvs value Close off pressure with 600N motor Close off pressure with 1800N motor Type
mm inch   kPa kPa
15 G1 1/8 0,63 1600 — V5011E1165  PDF
15 G1 1/8 1 1600 — V5011E1171  PDF
15 G1 1/8 1,6 1600 — V5011E1189  PDF
15 G1 1/8 2,5 1600 — V5011E1197  PDF
15 G1 1/8 4 1600 — V5011E1205  PDF
20 G1 1/4 6,3 1600 — V5011E1213  PDF
25 G1 1/2 10 1000 1600 V5011E1221  PDF
32 G2 16 700 1600 V5011E1229  PDF
40 G2 1/4 25 460 1500 V5011E1237  PDF
50 G2 3/4 40 260 850 V5011E1245  PDF
