Zone Valve - 4 Port 6.5mm Stroke PN16 Connex 15mm Kvs 0.4
SKU V5823C2017
Original price
£63.95
-
Original price
£63.95
Original price
£63.95
£63.95
-
£63.95
Current price
£63.95
Zone Valve - 4 Port 6.5mm Stroke PN16 Connex 15mm Kvs 0.4 - Datasheet en0b0308
![]() |
|
Valve series | V5823C |
Valve type | 3-way mixing, bypass |
Medium type | water |
Materials | body brass, stem stainless steel, plug brass |
Action to open | stem down |
Media temp. | 2 ... 120 oC |
Pressure rating | PN16 |
Port connection | ext. thread con. sealing |
Additional description | Valves are supplied with adjustment cap (not for on/off types). If the main-port (A-AB) is equal percentage, the B-AB port is linear. The valve capacity of B-AB is one stage smaller. |
|
||||||||||||||||||||
DN size | Connection diameter | Kvs value | Close off pressure with 90N motor | Close off pressure with 180N motor | Stroke | Flow char. | Type | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
mm | inch | kPa | kPa | mm | ||||||||||||||||
15 | G1/2 | 0,25 | 500 | 800 | 6,5 | mod.equal% |
V5823C2009 ![]() |
|||||||||||||
15 | G1/2 | 0,4 | 500 | 800 | 6,5 | mod.equal% |
V5823C2017 ![]() |
|||||||||||||
15 | G1/2 | 0,63 | 500 | 800 | 6,5 | mod.equal% |
V5823C2025 ![]() |
|||||||||||||
15 | G1/2 | 1 | 150 | 250 | 6,5 | mod.equal% |
V5823C2033 ![]() |
|||||||||||||
15 | G1/2 | 1,6 | 150 | 250 | 6,5 | mod.equal% |
V5823C2041 ![]() |
|||||||||||||
20 | 1 1/8" x 14 | 2,5 | — | 240 | 6,5 | mod.equal% |
V5823C2157 ![]() |
|||||||||||||
20 | 1 1/8" x 14 | 2,5 | 50 | 100 | 6,5 | mod.equal% |
V5823C2058 ![]() |
|||||||||||||
20 | 1 1/8" x 14 | 4 | — | 240 | 6,5 | mod.equal% |
V5823C2165 ![]() |
|||||||||||||
20 | 1 1/8" x 14 | 4 | 50 | 100 | 6,5 | mod.equal% |
V5823C2066 ![]() |
